Capabilities
Discover the solution that’s right for you.
CIRRIS 4250 TESTER
Easy-Wire software allows more options for test control, test archiving, and test reporting
- High Voltage: Test up to 1500 VDC up to 2000 VDC and 1000 VAC.
- All essential testing: Test for opens, shorts, miswires, and intermittent errors. Also test components such as resistors, diodes, and capacitors.
- Diodes: Silicon, LEDs, zeners with breakdown > 4 V
- Resistors: 0.1 Ω to 100 kΩ ± 1% ± 0.1 Ω, 100 kΩ to 5 MΩ ± 10%
- Capacitors: 5 nF to 100 μF ±10% ± 0.02 nF
- Twisted Pairs: Verify proper pairing in twisted pair cables
Motorized PULL Force Testers
ntelliMESUR® software is an integrated solution running on Windows tablets and PCs. Select a pre-loaded 10.1” tablet with mounting bracket or use your own Windows device. With IntelliMESUR®, you can create and run a wide range of basic and multi-step tests.Record data, and analyze data via IntelliMESUR® software.
- Limit testing to a load, break, or distance
- Height measurement
- Load holding
- Cycle testing
- Multi-step testing, utilizing any combination of the above functions
SumiMark® IV PLUS system
Ability to print markers at varying lengths ranging from 0.25” to 4” dramatically reducing waste
Systems are developed to meet stringent requirements of the Aerospace, Military and Mass Transit Industries.
- Print Resolution - 300 dpi
- Print Speed - 1 to 4 ips
- Effective Print Width - 3.25”
- Media Width - 1/16” to 2”
- Cut Length Range - 0.25” to 4”
- Adherence: SAE-AS5942
- MIL-STD-202G, Method 215J
Schleuniger HOTSTAMP 4140
The HotStamp 4140 is designed for economical, high quality marking of wires, cables and tubing. Character combinations and character sizes are freely selectable. Although primarily used for marking wires and cables, the HotStamp 4140 is suitable for marking all sorts of thermoplastic materials.
- Maximum 25
- 40 characters per wheel (all alphanumeric characters)
- Horizontal: 1.2 / 1.5 / 1.6 / 1.7 / 1.8 / 2.0 / 2.1 / 2.2 / 2.5 / 2.7 mm
- Vertical: 1.2 / 1.6 mm
- Foil material: PVC-Foil, Teflon-Foil
- Foil colors: black, white; on request: red, yellow, green, blue
